FLIR E53 Advanced Thermal Camera 240x180 with MSX, 24deg

  • IR Resolution of 240 x 180 (43,200 pixels)
  • Temp Range of -20°C to 120° C (-4°F to 480°F)
    • 0°C to 650°C (32°F to 1200°F)
  • Manual Focus
  • Image Frequency of 30Hz
  • MSZ®- Embosses visual details on full resolution thermal image
  • Quick-release battery is easy to remove, change, and recharge
  • Bluetooth communication sends data from MeterLink-enabled meters to the camera, embedding it into thermal images as you capture them
  • 2 years coverage on the camera, 5 on batteries, and 10 on the detector
SKU: FLIR-E53
FLIR

Availability: In stock

$10,500.00
Specifications
Specifications
OVERVIEW
Accuracy ±2°C (±3.6°F) or ±2% of reading for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)
Alarm Moisture, insulation, and measurement
Color alarm (isotherm) Above, below, interval, condensation, insulation
Detector Type Uncooled microbolometer, 17µm
Dimensions (L x W x H) 278.4 × 116.1 × 113.1 mm (11.0 × 4.6 × 4.4 in)
IR Resolution 240 × 180 (43,200 pixels)
Laser Pointer Yes; dedicated button
Object Temperature Range -20°C to 120°C (-4°F to 248°F) 0°C to 650°C (32°F to 1200°F)
Compass GPS Yes; automatic GPS image tagging
Area Box 1 in live mode
CONNECTIONS & COMMUNICATIONS
Communication Interfaces USB 2.0, Bluetooth, Wi-Fi, DisplayPort
Storage Media Removable SD card
Video Out DisplayPort over USB Type-C
METERLiNK Yes; several readings
ENVIRONMENTAL
Operating Temperature Range -15°C to 50°C (5°F to 122°F)
Storage Temperature Range -40°C to 70°C (-40°F to 158°F)
IMAGING & OPTICAL
Color palettes Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
Digital Camera 5 MP, 53° × 41° FOV
Digital Zoom 1-4x continuous
f-number f/1.3
Field of view (FOV) 24° × 18°
Focus Manual
Image Fequency 30 Hz
Image Modes Infrared, visual, MSX®, Picture-in-Picture
Non-radiometric IR video streaming H.264 or MPEG-4 over Wi-Fi; MJPEG over UVC or Wi-Fi
Picture-in-Picture Centered infrared area on the visual image
Radiometric IR video recording Real-time radiometric recording (.csq)
Radiometric IR video streaming Over UVC
Spectral Range 7.5 – 14.0 µm
Weight [incl lens] 1 kg (2.2 lbs)
MSX Embosses visual details on full resolution thermal image
Non-Radiometric IR & Visual Video Recording H.264 to memory card
MEASUREMENT & ANALYSIS
Measurement Presets No measurement, center spot, hot spot, cold spot, 3 spots, hot spot-spot
Spot Meter 3 in live mode
Thermal Sensitivity <0.04°C at 30°C (86°F), 24° lens
METER DATA
Display 4°, 640 × 480 pixel touch screen LCD with auto-rotation
OTHER
Shock and Vibration and Drop and Encapsulation 25 g / IEC 60068-2-27, 2 g / IEC 60068-2-6, IP 54 /IEC 60529; EN/UL/CSA/PSE 60950-1
POWER
Battery operating time Approx. 2.5 hours at 25°C (77°F) ambient temperature and typical use
Battery Type Li-ion battery, charged in camera or on separate charger
SHIPPING INFORMATION
Packaging Infrared camera with lens, battery (2 ea), battery charger, front protection, straps (hand, wrist), hard transport case, lanyards, lens caps, lens cleaning cloth, power supplies, 8 GB SD card, Torx wrench, cables (USB 2.0 A to USB Type-C, USB Type-C to USB Type-C, USB Type-C to HDMI)
STORAGE MEDIA
Image File Format Standard JPEG with measurement data included
Details
Details

The FLIR E53 is your entry into the Exx-Series, with the resolution and sensitivity you need at the right price. The 240 × 180 true native resolution offers more than 43,200 points of temperature measurement and produces crisp, vibrant imagery, which can be enhanced with FLIR's patented MSX® for added perspective.

Reimagined from the handle up

  • SUPERIOR SPOT-SIZE PERFORMANCE

    The E53's spot-size ratio allows you to take the most accurate temperature readings on smaller targets, at farther distances.

  • FEATURES TO HELP YOU TROUBLESHOOT

    The E53 measures up to 650°C (1200°F), offers 3 spotmeters and displays the max/min temperature within an area live, on-screen.

  • STREAMLINED REPORTING

    Customizable work folders, a built-in mic for voice annotation, and report generation features all help the E53 streamline your workday.

Additional
Additional
Model Name E53
Net Weight 1 kg (2.2 lbs)
Dimension 278.4 × 116.1 × 113.1 mm (11.0 × 4.6 × 4.4 in)
Style Handheld
IP Rating IP54
Detector resolution 240 x 180
Display Resolution 640 x 480
Display Size 4.0 inch
Display screen LCD
Temperature max 650 °C
Temperature min -20 °C
Frame rate 30 Hz
