FLIR E75 Advanced Thermal Camera 320x240 with MSX

  • IR Resolution: 320 x 240 (76,800 pixels)
  • Temperature Range: -4°F to 248°F, 32°F to 1200°F, Optional 572°F to 1830°F
  • Thermal Sensitivity/NETD: < 0.03°C @ 30°C (86°F)
  • Removable SD card (8 GB)
  • Image Format: Standard radiometric JPEG, measurement data included
  • Electrical and Mechanical Applications
    • Laser-assisted autofocus
    • Wide temperature ranges, up to 1500°C
    • Vibrant, 4” optically-bonded PCAP touchscreen with 160° viewing angle
    • Wi-Fi, METERLiNK® connectivity
    • Streamlined reporting features
    • FLIR’s industry-leading 2-5-10 warranty
  • Building Applications
    • Fast, precise laser-assisted autofocus
    • Grip, trigger, and buttons designed for easy one-handed operation
    • Sensitive enough to clearly identify hidden building deficiencies
    • On-screen area measurement (E85, E95)
    • True 42° field of view (FOV)
    • Wi-Fi, METERLiNK® connectivity
    • Streamlined reporting features
SKU: FLIR-E75
FLIR

Availability: In stock

$15,000.00

* Required Fields

Specifications
Specifications
OVERVIEW
Accuracy ±2°C (±3.6°F) or ±2% of reading for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)
Alarm Moisture alarm, insulation alarm, measurement alarms
Color alarm (isotherm) Above/below/interval/condensation/insulation
Cover Glass Material Dragontrail®
Difference Temperature Yes
Display Technology IPS
Housing material PCABS with TPE, magnesium
IR Resolution 320 x 240
Languages 21
Laser Class 2, 0.05–40 m (1.6–131 ft.) ±1% of measured distance
Object Temperature Range •–20 to +120°C (–4 to 248°F) •0–650°C (32–1200°F) •Optional 300–1000°C (572–1830°F)
Packaging Size 500 x 190 x 370 mm (19.7 x 7.5 x 14.6 in.)
Programmable Buttons 1
Resolution 640 × 480 pixels (VGA)
Screening 0.5°C (0.9°F) accuracy @ 37°C (98.6°F) with reference
Warranty http://www.flir.com/warranty/
Compass GPS Yes; automatic GPS image tagging
Text Text from predefined list or soft keyboard on touchscreen
Time Lapse [Infrared] No
Voice 60 seconds built-in microphone and speaker (and via Bluetooth) on still images and video
Weight & Dimensions (without lens) 1 kg (2.2 lbs), 27.8 x 11.6 x 11.3 cm (11.0 x 4.6 x 4.4 in)
CONNECTIONS & COMMUNICATIONS
Audio Microphone and speaker for voice annotation of images
Charging In camera (AC adapter or 12 V from a vehicle) or two-bay charger
Communication Interfaces USB 2.0, Bluetooth, Wi-Fi
Remote Control •Using FLIR Tools (using USB cable) •FLIR Tools Mobile (over Wi-Fi)
Storage Media Removable SD card (8 GB)
USB USB Type-C: data transfer/video/power
USB - Standard USB 2.0 High Speed
Video Out DisplayPort over USB Type-C
METERLiNK Wireless connection (Bluetooth) to: FLIR meters with METERLiNK
WiFi Peer to peer (ad hoc) or infrastructure (network)
Setup Commands Local adaptation of units, language, date and time formats
ENVIRONMENTAL
Drop Designed for 2 m (6.6 ft.)
EMC •ETSI EN 301 489-1 (radio) •ETSI EN 301 489-17 •EN 61000-6-2 (immunity) •EN 61000-6-3 (emission) •FCC 47 CFR Part 15 Class B (emission)
Emissivity Correction Yes: variable from 0.01 to 1.0 or selected from materials list
Operating Temperature Range –15°C to 50°C (5°F to 122°F)
Radio Spectrum •ETSI EN 300 328 •FCC Part 15.249 •RSS-247 Issue 2
Safety EN/UL/CSA/PSE 60950-1
Storage Temperature Range –40°C to 70°C (-40°F to 158°F)
Tripod Mounting UNC 1/4"–20
Shock & Vibration & Encapsulation 25 g / IEC 60068-2-27, 2 g / IEC 60068-2-6, IP 54 /IEC 60529; EN/UL/CSA/PSE 60950-1
IMAGING & OPTICAL
Aspect ratio 04:03
Auto Rotation Yes
Camera software update Use PC software FLIR Tools
Color Black
Color depth (bits) 00:00
Color palettes Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
Detector Type and Pitch Uncooled microbolometer, 17 µm
Digital Camera 5 MP, 53° x 41° FOV
Digital Zoom 1-4x continuous
Field of view match Yes
Focus Continuous, one-shot laser distance meter (LDM), one-shot contrast, manual
Gallery Yes
Image Adjustment •Automatic •Automatic maximum •Automatic minimum •Manual
Image Frequency 30 Hz
Image Modes Infrared, visual, MSX®, Picture-in-Picture
Image Sketch Yes: on infrared images only
Infrared Image Yes
Lens Identification Automatic
Non-Radiometric IR or Visual Video H.264 to memory card
Non-radiometric IR video streaming H.264 or MPEG-4 over Wi-Fi MJPEG over UVC or Wi-Fi
Picture-in-Picture Resizable and movable
Radiometric IR video recording Real-time radiometric recording (.csq)
Radiometric IR video streaming Over UVC
Spectral Range 7.5 - 14.0 µm
Viewfinder No
MSX Embosses visual details on full resolution thermal image
Sketch From touchscreen
UltraMax Super-resolution process quadruples pixel count, activated in FLIR Tools+
Viewing Angle 80°
Visual Video Streaming Yes
MEASUREMENT & ANALYSIS
Area 1 in live mode
Area measurement information No
Measurement Corrections Yes
Measurement Presets No measurement, center spot, hot spot, cold spot, User Preset 1, User Preset 2
Reference Temperature Yes
Spot Meter 3 in live mode
Laser Distance Measurement Yes, on-screen
Automatic hot & cold detection Auto-maximum/minimum markers within area
METER DATA
Display 4", 640 x 480 optically-bonded PCAP touchscreen, with 400 cd/m2 surface brightness
POWER
Battery Life (Operating) > 2.5 hours at 25°C (68°F) and typical use
Battery operating time Approx. 2.5 hours at 25°C (77°F) ambient temperature and typical use
Battery size (L x W x H) 150 × 46 × 55 mm (5.9 × 1.8 × 2.2 in.)
Battery Type Li-ion battery, charged in camera or on separate charger
Battery voltage 3.6 V
Battery weight 140 g (4.9 oz.)
Charging Temperature 0°C to +45°C (+32°F to +113°F)
Charging Time (using two-bay charger) 2.5 hours to 90% capacity with charging status indicated by LEDs
External Power Operation AC adapter 90–260 V AC, 50/60 Hz, or 12 V from a vehicle (cable with standard plug—optional)
Power Management Automatic shut-down and sleep mode
SHIPPING INFORMATION
Packaging Infrared camera with lens, battery (2 ea), battery charger with power supply, front lens and light protection, straps (hand and wrist), lanyards, lens caps (front and rear), lens cleaning cloth, 15 W3 A power supply, printed documentation, 8 GB SD card, Torx screwdriver, cables (USB 2.0 A to USB Type-C,USB Type-C to HDMI, USB Type-C to USB Type-C)
STORAGE MEDIA
Image File Format Standard radiometric JPEG, measurement data included
Details
Details

The FLIR E75 has the sensitivity and resolution needed to diagnose problems and find hidden deficiencies, even from a distance. The 320 x 240 true native resolution offers more than 76,000 points of temperature measurement and produces crisp, vibrant imagery, while interchangeable lenses offer complete coverage of near and distant targets.

Reimagined From The Handle Up

  • LASER DISTANCE MEASUREMENT

    The laser distance meter aids in quick, precise autofocusing, so you can ensure accurate temperature measurements, every time.

  • STREAMLINED REPORTING

    Customizable work folders, a built-in mic for voice annotation, and report generation features all help the E75 streamline your workday.

  • SLEEK BUT RUGGED

    With features such as scratch-resistant glass and a drop-tested chassis, the E75's design is about more than good looks.

Package
Package

Each Unit Includes

  • Infrared camera with lens
  • battery (2 ea)
  • battery charger with power supply
  • front lens and light protection
  • straps (hand and wrist)
  • lanyards
  • lens caps (front and rear)
  • lens cleaning cloth
  • 15 W3 A power supply
  • printed documentation
  • 8 GB SD card
  • Torx screwdriver
  • cables (USB 2.0 A to USB Type-C,USB Type-C to HDMI, USB Type-C to USB Type-C)
Additional
Additional
Model Name E75
Net Weight 1 kg (2.2 lbs)
Dimension 27.8 x 11.6 x 11.3 cm (11.0 x 4.6 x 4.4 in)
Style Handheld
IP Rating IP54
Spatial resolution 1.31 mRad
Detector resolution 320 x 240
Display Resolution 640 x 480
Display screen IPS
Temperature max 1000 °C
Temperature min -20 °C
Thermal sensitivity 40 mK
Frame rate 30 Hz
