FLIR E8 WiFi Thermal Camera 320X240 with WiFi

The FLIR E8 with Wi-Fi offers affordable, high-resolution thermal imaging with the added advantage of wireless connectivity. Find hidden electrical faults, mechanical issues, and sources of energy loss thanks to the E8's crisp 76,800 (320 × 240) pixel infrared resolution and MSX® image enhancements. Then, streamline your workload by uploading and sharing images and data over Wi-Fi to the FLIR Tools mobile app.

SKU: FLIR-E8-WiFi
FLIR

Availability: In stock

$6,600.00
Specifications
Specifications
OVERVIEW
Accuracy ±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F)
Detector Type Uncooled microbolometer
Field of view (FOV) 45° × 34°
IR Resolution 320 × 240 pixels
Multi Spectral Dynamic Imaging (MSX) IR image enhanced with visible camera detail
Object Temperature Range –20°C to 250°C (–4°F to 482°F)
Packaging Size 385 × 165 × 315 mm (15.2 × 6.5 × 12.4 in)
Thermal Sensitivity/NETD <0.06°C (0.11°F) / <60 mK
CONNECTIONS & COMMUNICATIONS
Interface USB Micro: Data transfer to and from PC and Mac device
WiFi •Standard: 802.11 b/g/n •Frequency range: •2400–2480 MHz •5150–5260 MHz •Max. output power: 15 dBm
ENVIRONMENTAL
Emissivity table/correction Emissivity table of predefined materials/variable from 0.1 to 1.0
Encapsulation/Drop IP 54 (IEC 60529)/2m (6.6 ft.)
IMAGING & OPTICAL
Camera weight incl battery 0.575 kg (1.27 lb.)
Color palettes Black & white, iron, and rainbow
Focus Focus free
Image Adjustment Automatic/Manual
Image Frequency 9 Hz
Image Modes Thermal MSX®, thermal, picture-in-picture, thermal blending, digital camera
Minimum Focus Distance 0.5 m (1.6 ft.)
Picture-in-Picture IR area on visual image
Digital Camera Resolution/FOV 640 × 480/55° × 43°
MEASUREMENT & ANALYSIS
Spot Meter Center spot; box with min./max.
METER DATA
Display 3.0 in. 320 × 240 color LCD
POWER
Battery type & operating time Rechargeable 3.6 V Li ion battery; approx. 4 hours typical use
STORAGE MEDIA
File Formats Standard JPEG, 14-bit measurement data included
Details
Details

Best-in-class Thermal Troubleshooting Value

  • WI-FI CONNECTIVITY

    Upload images and data to the FLIR Tools app over Wi-Fi, for instant sharing and reporting.

  • SUPERIOR RESOLUTION

    With its outstanding 76,800 pixel detector and ±2% accuracy, the E8 offers best-in-class image clarity.

  • THE POWER OF ONE BUTTON

    A focus-free lens and simple button navigation to on-screen settings makes this camera easy to operate.

Additional
Additional
Model Name E8 WiFi
Net Weight 0.575 kg (1.27 lb.)
Dimension 244 × 95 × 140 mm (9.6 × 3.7 × 5.5 in)
Style Handheld
IP Rating IP54
Spatial resolution 2.60 mRad
Detector resolution 320 x 240
Display Resolution 320 x 240
Display Size 3.0 inch
Display screen LCD
Temperature max 250 °C
Temperature min -20 °C
Thermal sensitivity 60 mK
Frame rate 9 Hz
